Volkswagen Amarok Exhaust 3L V6 TD 3" & 3.5" DPF Back Systems
2022-2025
Volkswagen Amarok 3L V6 TD 3" & 3.5" DPF-Back Exhaust Systems
For Volkswagen Amarok 3L V6 turbo diesel owners who want better flow and a deeper V6 note while keeping the factory DPF in place. Available in 3" or 3.5" pipework, in aluminised or 409 grade stainless steel. Bolt-on - no ECU remap or dyno tune required.
CNC mandrel-bent pipework with 10mm laser-cut flanges.
Product Specifications
- CNC mandrel-bent 3" (76mm) and 3.5" (89mm) pipework
- 10mm thick laser-cut flange plates
- Made in Australia
Available In
- Aluminised steel
- 409 grade stainless steel
Features
- Direct fit for Volkswagen Amarok 3L V6 turbo diesel
- DPF-back design retains the factory DPF
- Improved exhaust flow and throttle response
- Enhanced fuel economy and towing performance
- Deeper, more refined V6 exhaust tone
- Bolt-on installation - no ECU remapping or dyno tune required
Choose Your Configuration
All configurations are DPF-back and retain the factory DPF:
- Pipe Only
Fitment
- Vehicle: Volkswagen Amarok
- Engine: 3L V6 turbo diesel
- DPF status: DPF-equipped - this system retains the factory DPF
Warranty
Our 409 stainless steel and aluminised steel IGNITE Exhausts are backed by a 10 year warranty and 2 year Australian manufacturer warranty respectively.
Each product we sell comes with automatic guarantees that cannot be excluded under Australian law.
Should the item you receive be faulty in any way, please contact us and we"ll make sure the correct process is followed so the issue can be addressed as quickly as possible for you.
| Brand | IGNITE Exhausts |
| Shipping Weight | 24.0000kg |
| Shipping Width | 0.390m |
| Shipping Height | 0.250m |
| Shipping Length | 1.300m |
| Shipping Cubic | 0.126750000m3 |
- Remove Factory Exhaust Components (3" & 3.5" Systems) Remove the factory muffler and tailpipe assembly.
- 3" System: The new exhaust will slide into the factory slip joint where the original band clamp is located.
- 3.5" System: Remove the factory DPF connecting pipe as well as the pressure line attached to it.
Apply lubricant to the rubber hangers to make removal easier. - Install DPF Connector Pipe 3" System With the factory system removed, install the 3" DPF connector pipe using the original band clamp
- Install DPF Connector Pipe 3.5" System With the factory system removed, install the 3.5" DPF connector pipe using the original three bolts and gasket. Re-attach the pressure hose to the pressure fitting on the pipe.
- Install Mid Pipe 3.5" System Fit the mid pipe section and secure it with the supplied 3/8 UNC bolts and nuts. Ensure the gasket is properly seated between the flanges.
- Install Tailpipe 3" & 3.5" Systems Install the tailpipe section and fasten it using the supplied 3/8 UNC bolts and nuts. Confirm the gasket is correctly positioned between the flanges
- Check Clearances Ensure all components have adequate clearance from surrounding vehicle parts.
- Start-Up & Leak Inspection Start the vehicle and check all connections for leaks. Adjust as required.
- Completion Enjoy your new IGNITE Exhaust system.
Vehicle Applications
| Make | Model | Year Start - Year End | Series | Body Type | Engine Details | Drivetrain |
|---|---|---|---|---|---|---|
| Volkswagen | Amarok | 2022 - 2025 | T1A,T1B Ute 3.0 TDI 4motion | Ute | 3.0L | Diesel | AWD |
