Toyota Hilux N80 2.8L 3" & 3.5" DPF-Back Exhaust System

For Toyota Hilux N80 2.8L turbo diesel owners who want better flow and a deeper note while keeping the factory DPF in place. Bolt-on - no ECU remap or dyno tune required.

CNC mandrel-bent 3" and 3.5" pipework with thick laser-cut flanges.

Product Specifications

  • CNC mandrel-bent 3" and 3.5" pipework
  • Thick laser-cut flange plates
  • Made in Australia

Available In

  • Aluminised steel
  • 409 grade stainless steel

Features

  • Direct fit for Toyota Hilux N80 2.8L turbo diesel
  • DPF-back design retains the factory DPF
  • Improved exhaust flow and throttle response
  • Enhanced fuel economy and towing performance
  • Deeper, more refined exhaust tone
  • Bolt-on installation - no ECU remapping or dyno tune required

Choose Your Configuration

All configurations are DPF-back and retain the factory DPF:

  • Resonator
  • Muffler
  • Pipe Only
  • Diff Pipe Only

Looking for the DPF-delete turbo-back option? See the Turbo Back (DPF Delete) exhaust system options.

Fitment

  • Vehicle: Toyota Hilux N80
  • Engine: 2.8L turbo diesel
  • DPF status: DPF-equipped - this system retains the factory DPF

Warranty

Our 409 stainless steel and aluminised steel IGNITE Exhausts are backed by a 10 year warranty and 2 year Australian manufacturer warranty respectively.

Each product we sell comes with automatic guarantees that cannot be excluded under Australian law.

Should the item you receive be faulty in any way, please contact us and we"ll make sure the correct process is followed so the issue can be addressed as quickly as possible for you.

Varies between options.

Brand IGNITE Exhausts
Shipping Weight 10.0000kg
Shipping Width 0.390m
Shipping Height 0.250m
Shipping Length 1.300m
Shipping Cubic 0.126750000m3
  1. Remove rear tail pipe and muffler assembly from the vehicle.
  2. Remove centre connecting and DPF pipe from the vehicle.
  3. Using the factory DPF spring loaded bolts fit the DPF pipe and tighten finger tight.
  4. Fit the connecting pipe to the DPF pipe and tighten finger tight with the supplied 3/8 UNC nuts. (Fit diff pipe section in the same format if that’s what you purchased and then continue with step 7)
  5. Fit the pipe only/resonator or muffler section to the connecting pipe and tighten finger tight with the supplied 3/8 UNC nuts.
  6. Fit the tailpipe to the pipe only/resonator or muffler section and tighten finger tight with the supplied 3/8 UNC nuts.
  7. Check over exhaust making sure everything is aligned and then tighten all bolts and nuts from the front to back of the vehicle. If you have any fitting/alignment issues, please call 1300 12 13 12 as soon as possible to avoid damaging the exhaust system.
  8. Enjoy your IGNITE exhaust!

Vehicle Applications

Make Model Year Start - Year End Series Body Type Engine Details Drivetrain
Toyota Hilux 2015 - 2025 Ute 2.8 D-4D 4WD Ute 2.8L | Diesel AWD
Toyota Hilux 2015 - 2025 Ute 2.8 D-4D Ute 2.8L | Diesel RWD
Toyota Hilux 2015 - 2025 Platform/Chassis 2.8 D-4D Platform/Chassis 2.8L | Diesel RWD
Toyota Hilux 2015 - 2025 Ute 2.8 D-4D Ute 2.8L | Diesel RWD
Toyota Hilux 2015 - 2025 Platform/Chassis 2.8 D-4D 4WD Platform/Chassis 2.8L | Diesel AWD
Toyota Hilux 2015 - 2025 GUN123 Ute 2.8 D Ute 2.8L | Diesel RWD
Toyota Hilux 2015 - 2025 GUN123 Platform/Chassis 2.8 D Platform/Chassis 2.8L | Diesel RWD
Toyota Hilux 2015 - 2025 GUN126 Platform/Chassis 2.8 D 4WD Platform/Chassis 2.8L | Diesel AWD
Toyota Hilux 2015 - 2025 Ute 2.8 D-4D Ute 2.8L | Diesel RWD
Toyota Hilux 2015 - 2025 Platform/Chassis 2.8 D-4D 4WD Platform/Chassis 2.8L | Diesel AWD
Toyota Hilux 2015 - 2025 GUN126 Ute 2.8 D 4WD Ute 2.8L | Diesel AWD
Toyota Hilux 2015 - 2025 Ute 2.8 D-4D 4WD Ute 2.8L | Diesel AWD
Toyota Hilux 2015 - 2025 GUN136 Ute 2.8 D Ute 2.8L | Diesel RWD
