Product Details

Holden

HQ-HJ-HX-HZ-WB

283, 302, 305, 307, 327, 350, 400 V8 Small Block Chev Motor

Manual & Automatic

TRI-Y design

Important Notes

• Will fit Turbo 400 automatic

• Will fit Powerglide automatic

• Will not fit slant plug heads

• Will not fit raised port heads

• Will only fit with original engine mounting spacers or PACEMAKER spacers part number Pemp 350 Note: spacers must be fitted on correct side of vehicle. (RH spacer is 1¾” high, LH spacer is 1¼” high)


Product Specs

Part #:

PH 5320





P/Steering:

Yes

Gasket:

DSF 9

Air Con:

Yes

Primary Pipe:

1¾" (44mm)

Oxy Sen:

N/A

Secondary Pipe:

2" (51mm)

E.G.R:

N/A

Outlet:

2¼" (57mm)

Y Branch:

N/A

Fitting Time:

2 Hrs





***Disclaimer: Check over exhaust making sure everything is aligned and then tighten all bolts and nuts from the front to back of the vehicle. If you have any fitting/alignment issues, please call us as soon as possible to avoid damaging the exhaust system.***



SKU PH5320
Brand Pacemaker
Shipping Weight 12.0000kg
Shipping Width 0.390m
Shipping Height 0.250m
Shipping Length 1.130m
Shipping Cubic 0.110175000m3
