Product Details


Pacemaker Headers to suit

Holden

HK-HT-HG

283, 302, 305, 307, 327, 350, 400 V8 Small Block Chev Motor

Manual & Automatic

TRI-Y design



Important Notes

• Will fit slant plug heads

• Will fit Powerglide automatic

• Will not fit with Power Steering

Additional Information:

• Will fit Turbo 400 automatic if vehicles floor has been cut for correct fitment of automatic

• Will only fit with original engine mounting spacers or PACEMAKER spacers Part number Pemp 307

Note: spacers must be fitted on correct side of vehicle. (RH spacer is ¼” higher than LH spacer)

• Will not fit column automatic unless linkages are modified

• PH5302 headers are designed to fit with genuine factory starter when fitting to a 153 tooth (10 ½”) flex plate (auto only) or 153 tooth (13”) ring gear (manual only)

• PH5302 headers will not fit the genuine factory starter when fitting to 168 tooth (11”) flex plate (auto only) or 168 tooth (14”) ring gear (manual only). Pacemaker recommends the use of an after market hi-torque starter. Please choose carefully as not all starter solenoids are in the same position.



Product Specs

Part #:	PH 5302
P/Steering:	No	Gasket:	DSF 9
Air Con:	N/A	Primary Pipe:	1⅝" (41mm)
Oxy Sen:	N/A	Secondary Pipe:	2" (51mm)
E.G.R:	N/A	Outlet:	2¼" (57mm)
Y Branch:	N/A	Fitting Time:	3 Hrs

***Disclaimer: Check over exhaust making sure everything is aligned and then tighten all bolts and nuts from the front to back of the vehicle. If you have any fitting/alignment issues, please call us as soon as possible to avoid damaging the exhaust system.***
