Product Details


Pacemaker Headers to suit

Holden

HK-HT-HG

283, 302, 305, 307, 327, 350, 400 V8 Small Block Chev Motor

Manual & Automatic

TUNED design



Important Notes

• If required with alternator bracket on LH side order part number PH5306L & PH5305R

• Will fit slant plug heads

• Will fit Powerglide automatic

• Will fit Turbo 400 automatic if vehicles floor has been cut for correct fitment of automatic

• Will only fit with original engine mounting spacers or PACEMAKER spacers Part number Pemp 307

Note: spacers must be fitted on correct side of vehicle. (RH spacer is ¼” higher than LH spacer)

• Will only fit LH hydraulic clutch conversion

• Will not fit column automatic

• Will not fit with Power Steering



Product Specs

Part #:	PH 5305
P/Steering:	No	Gasket:	DSF 9
Air Con:	N/A	Primary Pipe:	1¾" (44mm)
Oxy Sen:	N/A	Secondary Pipe:	-
E.G.R:	N/A	Outlet:	3" (76mm)
Y Branch:	N/A	Fitting Time:	3 Hrs

***Disclaimer: Check over exhaust making sure everything is aligned and then tighten all bolts and nuts from the front to back of the vehicle. If you have any fitting/alignment issues, please call us as soon as possible to avoid damaging the exhaust system.***
