Product Description


Pacemaker Headers to suit

Falcon

FG - FGX

4 Litre

Manual & Automatic

TRI-Y design


Important Notes

• *Note - Fabrication is required*  These Headers do not bolt to a factory flange position. The original engine pipe needs to be cut in front of the cat. A extra flange is supplied to be welded to the original exhaust after the cut is made. This creates a flange point for the headers to bolt to.

Product Specs

Part #:	PH 4500
P/Steering:	Yes	Gasket:	DSF157
Air Con:	Yes	Primary Pipe:	1⅝" (41mm)
Oxy Sen:	Yes	Secondary Pipe:	2"
E.G.R:	N/A	Outlet:	2½" (63mm)
Y Branch:	N/A	Fitting Time:	1 ½ Hrs

***Disclaimer: Check over exhaust making sure everything is aligned and then tighten all bolts and nuts from the front to back of the vehicle. If you have any fitting/alignment issues, please call us as soon as possible to avoid damaging the exhaust system.***
