Product Description

Pacemaker Headers to suit

Holden

HQ-HJ-HX-HZ-WB

Fitted with

5 Litre E.F.I. Motor (Engine Conversion - 304 5L Holden V8 from VN, VP, VR, VS or VT Series 1)

or E.F.I. Heads installed onto original Holden V8 253-308 Block

Manual & Automatic Transmissions

TRI-Y design


Important Notes

• Will fit with High Energy Sump

• Will fit with HQ type Mechanical Clutch (Rat Trap Clutch)

These Headers will fit the following gearboxes:

• Australian four speed with cable clutch

• Commodore VN-VS five speed T5

• Toyota Supra five speed with Hatfield bellhousing

• Holden Trimatic

• Holden Turbo 400

• Holden Turbo 350

• Will fit with High Energy Sump HE2101 Part No.

• Commodore four speed automatic Turbo 700 with

Hatfield rear cross member using Turbo 700 gear box

mounts and 308 engine mounts



Product Specs

Part #:	PH 5270
P/Steering:	Yes	Gasket:	DSF 63
Air Con:	Yes	Primary Pipe:	1⅝" (41mm)
Oxy Sen:	Yes	Secondary Pipe:	1⅞" (48mm)
E.G.R:	N/A	Outlet:	2¼" (57mm)
Y Branch:	N/A	Fitting Time:	2 Hrs



***Disclaimer: Check over exhaust making sure everything is aligned and then tighten all bolts and nuts from the front to back of the vehicle. If you have any fitting/alignment issues, please call us as soon as possible to avoid damaging the exhaust system.***
